Low Electricity Consumption 5 Gallon Water Filling Machine Electric Driven

Zhangjiagang Jiayuan Machinery Co.,Ltd.
Contact Now

Low Electricity Consumption 5 Gallon Water Filling Machine Electric Driven

  • 1
  • 2
  • 3

Brand Name : JIAYUAN

Model Number : QGF-300

Certification : CE,ISO,SGS

Place of Origin : Jiangsu, China (Mainland)

MOQ : 1piece

Price : US $30,000 - 50000 / Set

Supply Ability : 10 Set/Sets per Month

Delivery Time : 30 working days

Packaging Details : wooden box

Material : stainless steel 304

Application : Beverage, Chemical, Food, Medical

Packaging Type : Barrel,Bottles, Cartons

Packaging Material : Paper, Plastic, Wood

Power : 3.8kw

After-sales Service Provided : Engineers available to service machinery overseas

Warranty : One year free

Power supply : 380V/50HZ(adjustable)

Processing Types : Water

Dimension(L*W*H) : 3800*1300*1600MM

Weight : 1200kg

Contact Now

5 gallon water filling machine with low water and electricity consumption

Product Description

Keyword: Filling Machine/Barreled Production Line/5gallons Washer Filler Capper Monoblock/120barreled Production Line/5gallons production line/5gallons barreled production line

5 gallon water filling machine with low water and electricity consumption

1.It has the following types:80 type,150 type,300 type,450 type,600 type,900 type.

2.It integrates bottle washer, filler and sealer into one unit. In order to achieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and bleaching are used in bottle washer,washing solution can be used circularly.

3.The sealer can seal barrel caps are aseptic and healthy,this line can also automatically carry out washing,sterilizing,filling, capping, counting and products discharging.It is a new kind of barreled water auto-producing line,which integrates mechanism, electricity and pneumatic technologies together.

Model QGF-80 QGF-150 QGF-300 QGF-450 QGF-600
Filling heads 1 1 2 3 4
Volume 18.9 18.9 18.9 18.9 18.9
Barrel size 270*490 270*490 270*490 270*490 270*490
Capacity 80 150 300
Gas pressure 0.4 -0.6 0.4 -0.6 0.4 -0.6 0.4 -0.6 0.4 -0.6
Gas consumption 0.37 0.37 0.6 0.8 1
Motor power 1.38 1.75 3.8 3.8 7.5
Motor voltage 380V/50HZ 380V/50HZ 380V/50HZ 380V/50HZ 380V/50HZ
Weight 500 700 1200 1600 2000
Dimension 2500*1100*1600 2800*1100*1600 3800*1300*1600 4200*1600*1600 4800*1800*1600

Low Electricity Consumption 5 Gallon Water Filling Machine Electric Driven

Low Electricity Consumption 5 Gallon Water Filling Machine Electric Driven

Low Electricity Consumption 5 Gallon Water Filling Machine Electric Driven

Our Services

Low Electricity Consumption 5 Gallon Water Filling Machine Electric Driven

Low Electricity Consumption 5 Gallon Water Filling Machine Electric Driven
