This carbonated beverage filling equipment adopts bottle neck holding transmission technology to realize fully automatic rinsing,filling and capping.It is equipped with CO2 accuracy pressure control,so that the liquid level is always stable.The application of alarm devices for bottle jam,bottle storage,bottle damage,cap storage,over loading etc.In several places ensure the quality of its production.The machine obtains advantages of high reliability,high efficiency,high grade of automation and easy operation,etc.
You can click this below picture to see the video:
https://www.youtube.com/watch?v=LtzlEBGCvAg&feature=share
Main features
1. It is applicable for carbonated drink filled in plastic bottles and capped with plastic caps, with optional capacity from 2000BPH to 28000BPH.
2. It is easy to change the shape of bottles, which can be done by changing the thumb wheel without adjusting the height of the machine.
3. Adopting suspensory transmission gear can easily upkeep and be repaired.
4. The machine case and the parts contacting with the materials are made of stainless steel which ensures the good external look and easy washing.
5. It uses frequency changer to conrtol the main machine motor. And it has an output number indicating function which is easy to control the adjustment of the output.
Technique parameter
| Model: | DCGF60-60-15 |
| Capacity :500ml | 24000BPH |
| Bottle shape: | Round or square |
| PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm |
| Cap: | PE srew cap |
| Filling precision: | ≤±5mm |
| Filling pressure:(Mpa) | 0.15-0.35 |
| Rinsing pressure:(Mpa) | 0.2-0.25 |
| Filling volume :(L) | 8 |
| Overall size:(mm) | 6600*6600*2600 |
| Weight: (kg) | 1t |
Characteristic
1). This machine operates easily, with compact structure, perfect control system and high level of automation.
2). The filling process of different types of bottles can be reached only by changing the star-wheel
3). The parts contacting with product is made of quality SUS, anti-corrosive, and easy to clean.
4). By adopting high speed filling valve, the liquid level is precise and no waste is to increase. That guarantees the demand of modern filling technology.
5). The capping head adopts constant torque magnetic device to guarantee capping quality, without any damage to the cap.
6). This machine has a highly efficient cap arranging system, perfect cap feeding and protection device.
7). The machine is convenient to adjust the amchine to fill various types of bottles.
8). The filling operation is faster and more stable due to the isobar filling operation of the new type is adopted.
9). The output and benefit of the machine is higher than the machines of the same specification.
10). It is convenient to operate with higher automation due to every parts of the machine is inspected to run with photo electrical detector.
11). The machine is idea-preferred equipment for beverage maker.
